TEBCO PIONEER
$3,599.00
Out of stock
Description
Folds down in seconds! Designed for
compact storage & easy transportation.
AN IMPORTANT NOTE ON TRICYCLE PURCHASES
Please note that our TEBCO Electric Tricycles are only available for purchase in-store. They are not available for online purchase.
Whilst we could all ride a 3-wheel tricycle when we were 5 years old - later in life it can actually prove quite difficult switching from 2 wheels to 3. So, in the interest of our customers' safety and satisfaction, TEBCO will only sell a 3-wheeled Electric Tricycle after a customer has taken a test ride to ensure they are comfortable.
If you would like to purchase one of our Electric Tricycles, please call TEBCO on 03 9584 3000 so we can answer any questions you may have and direct you to your nearest store for a test ride before purchase.
TEBCO PIONEER
The ULTIMATE FOLDING TRICYCLE. Folds down in seconds! Designed for compact storage & easy transportation.
FEATURES
20in Wheels Front and Rear
Weight– 41kg including battery
Max. speed 25kmh / Max. range 60km
250W Rear Wheel Drive Motor
36V 14.5Ah (522Wh) Samsung Lithium Battery
Folding Frame for Portability
7 Speed Electronic Shifting With Torque Sensor
High Quality 2.25in Innova Tyres
Colour Indicator / Trip Computer / Speedo / Battery Gauge
Disc Brakes Front and Rear
Rear Axle Differential for Enhanced Manoeuvrability
Heavy Duty Alloy Tube Basket with Utility Bag
No licence or registration required
SPECIFICATIONS
Mechanical |
|
|---|---|
| Frame | 6061 Grade Alloy |
| Wheel Size | 20in 36h Front And Rear |
| Fork | VIBEE WB325-20″ Teethless Headtube @28.6 *205mm, Travel Distance: 40mm |
| Handlebar | ZOOM Mtb-Al-153 Alloy 620mm H:30mm |
| Stem | FH05W 28.6*25mm(H) |
| Seatpost | Alloy 33.9mm X 350mm |
| Seat Clamp | Alloy 38.1mm |
| Saddle | TEBCO Tush Cush AQ 6050 |
| Shifters | Magene Electronic Shifting ED20 |
| Derailleur | Shimano RD-TyY00 7 Speed |
| Rims | C-Stars J25SE 20inch 36h Double Wall Alloy |
| Hubs | Front Hub Alloy JA159F With Quick Release Rear Hub Alloy |
| Spokes | F 13g 2.2mm / R 13g 2.2mm Stainless Steel |
| Tyres | Innova IA-2131 20in*2.25in |
| Cranks | Pb4b104s-42/32 170mm 42t |
| Pedals | Wellgo F178 |
| Chain | 27,1/2*3/32″*1081, Z1ehx, 1/2″*1/8″*441 |
| Brakes Front | Se-P1816 Front Disc Brake |
| Brakes Rear | Se-P1816 Rear Disc Brake |
| Brake Levers | Wuxing 108ppd/4 Locking With Power Cut Off |
| Mudguards | Black Plastic 20in X 60mm |
Electrical |
|
|---|---|
| Motor | Bafang Sutto 20in 36v 250w M110 |
| Controller | 15Amp Magene CR30 |
| Battery | 36v 14.5Ah (522Wh) Lithium |
| Battery Life | 500 Cycles ≥70% Capacity |
| Battery Weight | 2.9kg |
| Display Panel | Magene Full Colour |
| Twist Grip Acc Assy | Wuxing 130X |
| Pedal Activation | Magene SR20 Torque Sensor |
| Light Front | XC-259A 50lux Static Illumination |
| Light Rear | Cedite DR011 |
| Charger | Keyu 36v 2Amp Lithium AU Compliant |
| Main Cable | 12 Waterproof Quick Release |
| Audible Warning | Honka Hoota Black |
| Max Speed | 25kmh |
| Max Range | 60km 1:1 Pedal Assist |
| Tricycle Weight | 38.9kg Incl Battery |
Sizing |
|
|---|---|
| Length | 1830mm |
| Width | 720mm |
| Max Seat Height | 1020mm |
| Min Seat Height | 800mm |
TEBCO PIONEER |
$3599 |
| Find a Store |
GOT ANY QUESTIONS? CALL (03) 9584 3000 OR EMAIL US TODAY!
FEATURED ACCESSORIES
Additional information
| Color | PORSCHE BLUE, FERRARI RED |
|---|
